16-14 NON-INSULATED BUTTED SEAM MULTI-STACK DISCONNECT

Find alt
772-250-A

772-250-A

Active
3M Electronic Specialty

16-14 NON-INSULATED BUTTED SEAM MULTI-STACK DISCONNECT

Find alt

Description

General part information

772-250-A

16-14 NON-INSULATED BUTTED SEAM MULTI-STACK DISCONNECT

Technical Specifications

Parameters and characteristics for this part

Specification772-250-A
FeaturesButted Seam
GenderFemale, Male
InsulationNon-Insulated
Mounting TypeFree Hanging (In-Line)
Tab Thickness0.032 in
Tab Width0.25 in
Terminal TypeStacked
TerminationCrimp
Wire Gauge (AWG) (Max)16 AWG
Wire Gauge (AWG) (Min)14 AWG
