LR6 G07/BF2X5
ActiveFDK America, Inc.
BATTERY PACK ALKALINE 15V AA
LR6 G07/BF2X5
ActiveFDK America, Inc.
BATTERY PACK ALKALINE 15V AA
Description
General part information
LR6 G07/BF2X5
AA 15 V Alkaline Manganese Dioxide Battery Pack
Technical Specifications
Parameters and characteristics for this part
| Specification | LR6 G07/BF2X5 |
|---|---|
| Battery Cell Size | AA |
| Battery Chemistry | Alkaline Manganese Dioxide |
| Capacity (Charge) | 2.875 Ah |
| Number of Cells | 10 |
| Rechargeability | No |
| Size / Dimension Height | 1.99 in |
| Size / Dimension Length | 2.85 in |
| Size / Dimension Width | 1.14 in |
| Structure | Side to Side |
| Structure Cells | 2 |
| Structure Rows | 5 |
| Termination Style | Solder Tab |
| Voltage - Rated | 15 V |
| Weight | 240 g |
