MAXQ610-KIT#
ActiveAnalog Devices Inc./Maxim Integrated
MAXQ610 EVAL BRD
Deep-Dive with AI
Search across all available documentation for this part.
MAXQ610-KIT#
ActiveAnalog Devices Inc./Maxim Integrated
MAXQ610 EVAL BRD
Deep-Dive with AI
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | MAXQ610-KIT# | MAXQ610 Series |
|---|---|---|
| - | - | |
| Board Type | Evaluation Platform | Evaluation Platform |
| Connectivity | - | SPI, UART/USART |
| Contents | Cable(s), Board(s) | Cable(s), Board(s) |
| Core Processor | MAXQ20S | MAXQ20S |
| Core Size | - | 16-Bit |
| Mounting Type | Fixed | Fixed, Surface Mount |
| Number of I/O | - | 20 - 32 |
| Operating Temperature | - | 70 °C |
| Operating Temperature | - | 0 °C |
| Oscillator Type | - | Internal |
| Package / Case | - | 40-WFQFN Exposed Pad, 44-WFQFN Exposed Pad, 32-LQFP |
| Peripherals | - | WDT, POR, Power-Fail, Infrared, Brown-out Detect/Reset |
| Program Memory Size | - | 64 KB |
| Program Memory Type | - | FLASH |
| RAM Size | - | 2K x 8 |
| Speed | - | 12 MHz |
| Supplier Device Package | - | 32-TQFN (5x5), 40-TQFN, 44-TQFN (7x7), 32-LQFP (7x7) |
| Type | MCU 16-Bit | MCU 16-Bit |
| Utilized IC / Part | MAXQ610 | MAXQ610 |
| Voltage - Supply (Vcc/Vdd) | - | 3.6 V |
| Voltage - Supply (Vcc/Vdd) | - | 1.7 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 189.86 | |
MAXQ610 Series
MAXQ610 EVAL BRD
| Part | Board Type | Contents | Utilized IC / Part | Type | Core Processor | Mounting Type | Supplier Device Package | Oscillator Type | Operating Temperature [Max] | Operating Temperature [Min] | Program Memory Size | Speed | Connectivity | RAM Size | Voltage - Supply (Vcc/Vdd) [Max] | Voltage - Supply (Vcc/Vdd) [Min] | Program Memory Type | Number of I/O | Peripherals | Core Size | Package / Case |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Analog Devices Inc./Maxim Integrated MAXQ610-KIT# | Evaluation Platform | Board(s), Cable(s) | MAXQ610 | MCU 16-Bit | MAXQ20S | Fixed | |||||||||||||||
Analog Devices Inc./Maxim Integrated MAXQ610A-0000+ | MAXQ20S | Surface Mount | 32-TQFN (5x5) | Internal | 70 °C | 0 °C | 64 KB | 12 MHz | SPI, UART/USART | 2K x 8 | 3.6 V | 1.7 V | FLASH | 24 | Brown-out Detect/Reset, Infrared, POR, Power-Fail, WDT | 16-Bit | |||||
Analog Devices Inc./Maxim Integrated MAXQ610A-9410+ | MAXQ20S | Surface Mount | 32-TQFN (5x5) | Internal | 70 °C | 0 °C | 64 KB | 12 MHz | SPI, UART/USART | 2K x 8 | 3.6 V | 1.7 V | FLASH | 24 | Brown-out Detect/Reset, Infrared, POR, Power-Fail, WDT | 16-Bit | |||||
Analog Devices Inc./Maxim Integrated MAXQ610B-0000+ | MAXQ20S | Surface Mount | 40-TQFN | Internal | 70 °C | 0 °C | 64 KB | 12 MHz | SPI, UART/USART | 2K x 8 | 3.6 V | 1.7 V | FLASH | 32 | Brown-out Detect/Reset, Infrared, POR, Power-Fail, WDT | 16-Bit | 40-WFQFN Exposed Pad | ||||
Analog Devices Inc./Maxim Integrated MAXQ610J-0000+ | MAXQ20S | Surface Mount | 44-TQFN (7x7) | Internal | 70 °C | 0 °C | 64 KB | 12 MHz | SPI, UART/USART | 2K x 8 | 3.6 V | 1.7 V | FLASH | 32 | Brown-out Detect/Reset, Infrared, POR, Power-Fail, WDT | 16-Bit | 44-WFQFN Exposed Pad | ||||
Analog Devices Inc./Maxim Integrated MAXQ610E-0000+ | MAXQ20S | Surface Mount | 32-LQFP (7x7) | Internal | 70 °C | 0 °C | 64 KB | 12 MHz | SPI, UART/USART | 2K x 8 | 3.6 V | 1.7 V | FLASH | 20 | Brown-out Detect/Reset, Infrared, POR, Power-Fail, WDT | 16-Bit | 32-LQFP | ||||
Analog Devices Inc./Maxim Integrated MAXQ610J-0000+T | |||||||||||||||||||||
Analog Devices Inc./Maxim Integrated MAXQ610K-0000+ | MAXQ20S | Surface Mount | 44-TQFN (7x7) | Internal | 70 °C | 0 °C | 64 KB | 12 MHz | SPI, UART/USART | 2K x 8 | 3.6 V | 1.7 V | FLASH | 32 | Brown-out Detect/Reset, Infrared, POR, Power-Fail, WDT | 16-Bit | 44-WFQFN Exposed Pad | ||||
Analog Devices Inc./Maxim Integrated MAXQ610J-0000+T | MAXQ20S | Surface Mount | 44-TQFN (7x7) | Internal | 70 °C | 0 °C | 64 KB | 12 MHz | SPI, UART/USART | 2K x 8 | 3.6 V | 1.7 V | FLASH | 32 | Brown-out Detect/Reset, Infrared, POR, Power-Fail, WDT | 16-Bit | 44-WFQFN Exposed Pad |
Description
General part information
MAXQ610 Series
MAXQ610 MAXQ® MAXQ20S MCU 16-Bit Embedded Evaluation Board
