CO32D6-40.000-18JDTSTK
ActiveSuzhou Hangjing Elec&Tech Co.,Ltd
XTAL OSC XO 40.0000MHZ LVDS SMD
CO32D6-40.000-18JDTSTK
ActiveSuzhou Hangjing Elec&Tech Co.,Ltd
XTAL OSC XO 40.0000MHZ LVDS SMD
Description
General part information
CO32D6-40.000-18JDTSTK
40 MHz XO (Standard) LVDS Oscillator 1.8V Enable/Disable 6-SMD, No Lead
Technical Specifications
Parameters and characteristics for this part
| Specification | CO32D6-40.000-18JDTSTK |
|---|---|
| Base Resonator | Crystal |
| Current - Supply (Max) | 100 mA |
| Frequency | 40 MHz |
| Frequency Stability | 20 ppm, 30 ppm |
| Function | Enable, Disable |
| Height - Seated (Max) | 0.051 in |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Output | LVDS |
| Package / Case | No Lead, 6-SMD |
| Size / Dimension Length | 0.126 in |
| Size / Dimension Width | 0.098 in |
| Type | XO (Standard) |
| Voltage - Supply | 1.8 V |
