24824-01-BX
ActiveLITTELFUSE
CVP RELAY
24824-01-BX
ActiveLITTELFUSE
CVP RELAY
Description
General part information
24824-01-BX
CVP RELAY
Technical Specifications
Parameters and characteristics for this part
| Specification | 24824-01-BX |
|---|---|
| Coil Current | 750 mA |
| Coil Type | Non Latching |
| Coil Voltage | 24 VDC |
| Contact Form | SPST-NO |
| Contact Material | Silver (Ag) |
| Contact Rating (Current) | 225 A |
| Form A Count | 1 |
| Mounting Type | Chassis Mount |
| Operating Temperature (Max) | 60 °C |
| Operating Temperature (Min) | -40 °C |
| Relay Type | General Purpose |
| Switching Voltage DC (Max) | 27 VDC |
| Termination Style | Stud |
