5532903-7
ActiveTE Connectivity AMP Connectors
ASSY,RECPT,R.ANGLE,HDI,LEAD-FREE,4ROW,W/
5532903-7
ActiveTE Connectivity AMP Connectors
ASSY,RECPT,R.ANGLE,HDI,LEAD-FREE,4ROW,W/
Description
General part information
5532903-7
PCB Mount Receptacle, Right Angle, Board-to-Board, 200 Position, 2.54 mm [.1 in] Centerline, Gold (Au), Through Hole - Solder, Signal, Black, Tube
Technical Specifications
Parameters and characteristics for this part
| Specification | 5532903-7 |
|---|---|
| Color | Brown |
| Connector Style | High Density (HDC, HDI, HPC) |
| Connector Type | Receptacle, Female Sockets |
| Contact Finish | Gold |
| Contact Finish Thickness | 30 µin |
| Features | Mating Guide |
| Mounting Type | Through Hole, Right Angle |
| Number of Positions | 200 |
| Number of Positions Loaded | All |
| Number of Rows | 4 |
| Pitch | 0.1 in |
| Termination | Solder |
