Y00692K00000J9L
ActiveVPG Foil Resistors
TRIMMER 2K OHM 0.25W PC PIN TOP
Y00692K00000J9L
ActiveVPG Foil Resistors
TRIMMER 2K OHM 0.25W PC PIN TOP
Description
General part information
Y00692K00000J9L
2 kOhms 0.25W, 1/4W PC Pins Through Hole Trimmer Potentiometer Metal Foil 21.0 Turn Top Adjustment
Technical Specifications
Parameters and characteristics for this part
| Specification | Y00692K00000J9L |
|---|---|
| Adjustment Type | Top Adjustment |
| Mounting Type | Through Hole |
| Number of Turns | 21 turns |
| Power (Watts) | 250 mW |
| Power (Watts) Options | 1/4W |
| Resistance | 2 kOhm |
| Resistive Material | Metal Foil |
| Size / Dimension Length | 0.375 in |
| Size / Dimension Shape | Rectangular |
| Size / Dimension Width | 0.17 in |
| Temperature Coefficient | 10 ppm/°C |
| Termination Style | PC Pins |
| Tolerance | 5 % |
