Specification	EEU-FS1A182L

Applications	General Purpose
Capacitance	1800 µF
Height - Seated (Max)	0.866 in
Impedance	30 mOhm
Lead Spacing	0.138 in
Lifetime	9000 Hrs
Mounting Type	Through Hole
Operating Temperature (Max)	105 °C
Operating Temperature (Min)	-40 °C
Package / Case	Can, Radial
Polarization	Polar
Ripple Current	1.248 A, 1.56 A
Size / Dimension Diameter	0.315 in
Tolerance	20 %
Voltage - Rated	10 V

EEU-FS Series

...

Part	Capacitance	Operating Temperature (Min)	Operating Temperature (Max)	Applications	Height - Seated (Max)	Ripple Current	Impedance	Tolerance	Voltage - Rated	Package / Case	Lifetime	Lead Spacing	Polarization	Size / Dimension Diameter	Mounting Type
Panasonic Electronic Components EEU-FS1V272B	2700 µF	-40 °C	105 °C	General Purpose	1.063 in	3.056 A 3.82 A	14 mOhm	20 %	35 V	Can Radial	10000 Hrs	0.295 in	Polar	0.63 in	Through Hole
Panasonic Electronic Components EEU-FS1H270B	27 µF	-40 °C	105 °C	General Purpose	0.492 in	137.5 mA 250 mA	0.34 Ohms	20 %	50 V	Can Radial	5000 Hrs	0.197 in	Polar	0.197 in	Through Hole
Panasonic Electronic Components EEU-FS1J102	1000 µF	-40 °C	105 °C	General Purpose	1.004 in	2.241 A 2.988 A	24 mOhms	20 %	63 V	Can Radial	10000 Hrs	0.295 in	Polar	0.63 in	Through Hole
Panasonic Electronic Components EEU-FS1J181LB	180 µF	-40 °C	105 °C	General Purpose	0.807 in	651 mA 930 mA	50 mOhm	20 %	63 V	Can Radial	9000 Hrs	0.197 in	Polar	0.315 in	Through Hole
Panasonic Electronic Components EEU-FS1K271LB	270 µF	-40 °C	105 °C	General Purpose	1.063 in	1.2 A 840 mA	44 mOhm	20 %	80 Vp-p	Can Radial	10000 Hrs	0.197 in	Polar	0.394 in	Through Hole
Panasonic Electronic Components EEU-FS1J181B	180 µF	-40 °C	105 °C	General Purpose	16.51 mm	1.073 A 751.1 mA	45 mOhm	20 %	63 V	Can Radial	8000 Hrs	0.197 in	Polar	0.394 in	Through Hole
Panasonic Electronic Components EEU-FS2A391	390 µF	-40 °C	105 °C	General Purpose	1.063 in	1.875 A 2.5 A	25 mOhms	20 %	100 VAC/DC	Can Radial	10000 Hrs	0.295 in	Polar	0.63 in	Through Hole
Panasonic Electronic Components EEU-FS1E122B	1200 µF	-40 °C	105 °C	General Purpose	0.866 in	1.744 A 2.18 A	20 mOhm	20 %	25 VAC	Can Radial	10000 Hrs	0.197 in	Polar	0.394 in	Through Hole
Panasonic Electronic Components EEU-FS2A270	27 µF	-40 °C	105 °C	General Purpose	0.512 in	269.5 mA 490 mA	0.16 Ohms	20 %	100 VAC/DC	Can Radial	6000 Hrs	0.138 in	Polar	0.315 in	Through Hole
Panasonic Electronic Components EEU-FS1K470	47 µF	-40 °C	105 °C	General Purpose	0.512 in	343 mA 490 mA	0.16 Ohms	20 %	80 Vp-p	Can Radial	6000 Hrs	0.138 in	Polar	0.315 in	Through Hole
