EDC104Z6R3C
ActiveCornell Dubilier Knowles
0.1F, 6.3V
EDC104Z6R3C
ActiveCornell Dubilier Knowles
0.1F, 6.3V
Description
General part information
EDC104Z6R3C
100 mF (EDLC) Supercapacitor 6.3 V Radial, Can 120Ohm @ 1kHz 1000 Hrs @ 70°C
Technical Specifications
Parameters and characteristics for this part
| Specification | EDC104Z6R3C |
|---|---|
| Capacitance | 0.1 F |
| ESR (Equivalent Series Resistance) | 120 Ohm |
| Height - Seated (Max) | 0.374 in |
| Lead Spacing | 0.197 in |
| Lifetime | 1000 Hrs |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 70 °C |
| Operating Temperature (Min) | -25 °C |
| Package / Case | Can, Radial |
| Size / Dimension Diameter | 0.531 in |
| Termination | PC Pins |
| Tolerance (Negative) | 20 % |
| Tolerance (Positive) | 80 % |
| Voltage - Rated | 6.3 V |
