Description
General part information
1XJN002UEE
Pushbutton Switch DPDT Standard Through Hole
Technical Specifications
Parameters and characteristics for this part
| Specification | 1XJN002UEE |
|---|---|
| Actuator Marking | No Marking |
| Actuator Type | Plunger for Cap |
| Circuit | DPDT |
| Color - Actuator/Cap | Blue |
| Current Rating | 100 mA |
| Electrical Life (Cycles) | 10000 Cycles |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 80 °C |
| Operating Temperature (Min) | -20 °C |
| Switch Function | On-On |
| Termination Style | PC Pin |
| Type | Standard |
| Voltage Rating - DC | 30 V |
