SPM10040T-1R5M-HZR
ActiveTDK Corporation
POWER INDUCTOR, 1.5UH, SHIELDED, 16.6A ROHS COMPLIANT: YES
SPM10040T-1R5M-HZR
ActiveTDK Corporation
POWER INDUCTOR, 1.5UH, SHIELDED, 16.6A ROHS COMPLIANT: YES
Description
General part information
SPM10040T-1R5M-HZR
1.5 µH Shielded Wirewound Inductor 17.2 A 4.29mOhm Max Nonstandard
Technical Specifications
Parameters and characteristics for this part
| Specification | SPM10040T-1R5M-HZR |
|---|---|
| Current - Saturation (Isat) | 16.6 A |
| Current Rating | 17.2 A |
| DC Resistance (DCR) (Max) | 4.29 mOhm |
| Height - Seated (Max) | 0.157 in |
| Inductance | 1.5 µH |
| Inductance Frequency - Test | 100 kHz |
| Material - Core | Metal |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Nonstandard |
| Ratings | AEC-Q200 |
| Shielding | Shielded |
| Size / Dimension Length | 0.421 in |
| Size / Dimension Width | 0.394 in |
| Tolerance | 20 % |
| Type | Wirewound |
