RVCA2010JT1M30
ActiveStackpole Electronics Inc
RES, HV, 2010, 1.3 MOHM, 5%, 0.5
RVCA2010JT1M30
ActiveStackpole Electronics Inc
RES, HV, 2010, 1.3 MOHM, 5%, 0.5
Description
General part information
RVCA2010JT1M30
1.3 MOhms ±5% 0.5W, 1/2W Chip Resistor 2010 (5025 Metric) Anti-Sulfur, Automotive AEC-Q200, High Voltage Thick Film
Technical Specifications
Parameters and characteristics for this part
| Specification | RVCA2010JT1M30 |
|---|---|
| Composition | Thick Film |
| Features | Automotive AEC-Q200, Anti-Sulfur, High Voltage |
| Height - Seated (Max) | 0.026 in |
| Number of Terminations | 2 |
| Operating Temperature (Max) | 155 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | 2010 (5025 Metric) |
| Package Name | 2010 |
| Power (Watts) | 500 mW |
| Power (Watts) Options | 1/2W |
| Ratings | AEC-Q200 |
| Resistance | 1.3 MOhm |
| Size / Dimension Length | 0.197 in |
| Size / Dimension Width | 0.098 in |
| Temperature Coefficient | 200 ppm/°C |
| Tolerance | 5 % |
