15M150M
ActiveGowanda Electronics
MOLDED UNSHIELDED RF COILS AXIAL
15M150M
ActiveGowanda Electronics
MOLDED UNSHIELDED RF COILS AXIAL
Description
General part information
15M150M
150 nH Unshielded Molded Inductor 2.45 A 30mOhm Max Axial
Technical Specifications
Parameters and characteristics for this part
| Specification | 15M150M |
|---|---|
| Current Rating | 2.45 A |
| DC Resistance (DCR) (Max) | 30 mOhm |
| Frequency - Self Resonant | 525 MHz |
| Inductance | 150 nH |
| Inductance Frequency - Test | 25 MHz |
| Material - Core | Phenolic |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | Axial |
| Package Name | Axial |
| Q | 50 |
| Shielding | Unshielded |
| Size / Dimension Diameter | 0.156 in |
| Size / Dimension Length | 0.375 in |
| Tolerance | 20 % |
| Type | Molded |
