RCS-1800-250
ActiveAim Dynamics
CURRENT SEN ROGOWSKI COIL 250A
RCS-1800-250
ActiveAim Dynamics
CURRENT SEN ROGOWSKI COIL 250A
Description
General part information
RCS-1800-250
Current Sensor 250A 3 Channel AC Single Phase/Three Phase Module
Technical Specifications
Parameters and characteristics for this part
| Specification | RCS-1800-250 |
|---|---|
| Accuracy | 1 % |
| Current - Sensing | 250 A |
| For Measuring | AC |
| Mounting Type | Chassis Mount |
| Number of Channels | 3 |
| Operating Temperature (Max) | 105 °C |
| Operating Temperature (Min) | -20 °C |
| Output | Voltage, Ratiometric |
| Package / Case | Module |
| Sensor Type | AC Single Phase/Three Phase |
| Voltage - Supply (Maximum) | 36 VDC |
| Voltage - Supply (Minimum) | 9 VDC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
No documents available
