5 PSI-GF-CGRADE-MINI

Active

Amphenol All Sensors Corporation

SENSOR 5PSIG 0.18" .06V

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	5 PSI-GF-CGRADE-MINI	GF-CGRADE-MINI Series

Accuracy	1 %	1 %
Applications	Board Mount	Board Mount
Features	Temperature Compensated	Temperature Compensated
Maximum Pressure	20 PSI	3 - 20 PSI
Maximum Pressure	137.9 kPa	20.68 - 137.9 kPa
Maximum Pressure	-	60 PSI
Maximum Pressure	-	413.69 kPa
Mounting Type	Through Hole	Through Hole
Operating Pressure	34.47 kPa	2.49 - 34.47 kPa
Operating Pressure	5 PSI	0.36 - 5 PSI
Operating Pressure	-	0.15 PSI
Operating Pressure	-	1 kPa
Operating Pressure	-	2.07 kPa
Operating Pressure	-	0.3 PSI
Operating Pressure	-	15 PSI
Operating Pressure	-	103.42 kPa
Operating Temperature [Max]	85 °C	85 °C
Operating Temperature [Min]	-25 °C	-25 °C
Output	12V	12V
Output [Max]	60 mV	20 - 90 mV
Output [Min]	0 mV	0 mV
Output Type	Wheatstone Bridge	Wheatstone Bridge
Package / Case	4-SIP Module	4-SIP Module
Port Style	Barbless	Barbless
Pressure Type	Vented Gauge	Vented Gauge
Termination Style	PC Pin	PC Pin
Voltage - Supply	16 VDC	16 VDC

GF-CGRADE-MINI Series

SENSOR 0.15PSIG 0.18" .025V

Part	Mounting Type	Operating Temperature [Min]	Operating Temperature [Max]	Applications	Pressure Type	Output Type	Output [Max]	Operating Pressure [x]	Operating Pressure [x]	Accuracy	Voltage - Supply	Package / Case	Termination Style	Features	Port Style	Maximum Pressure	Maximum Pressure	Operating Pressure [custom]	Operating Pressure [custom]	Operating Pressure	Operating Pressure	Output	Operating Pressure [custom]	Operating Pressure [custom]	Maximum Pressure [Max]	Maximum Pressure [Max]
Amphenol All Sensors Corporation 4 INCH-GF-CGRADE-MINI	Through Hole	-25 °C	85 °C	Board Mount	Vented Gauge	Wheatstone Bridge	25 mV	0.15 PSI	1 kPa	1 %	16 VDC	4-SIP Module	PC Pin	Temperature Compensated	Barbless	20.68 kPa	3 PSI
Amphenol All Sensors Corporation 0.3 PSI-GF-CGRADE-MINI	Through Hole	-25 °C	85 °C	Board Mount	Vented Gauge	Wheatstone Bridge	20 mV			1 %	16 VDC	4-SIP Module	PC Pin	Temperature Compensated	Barbless	20.68 kPa	3 PSI	2.07 kPa	0.3 PSI
Amphenol All Sensors Corporation 5 PSI-GF-CGRADE-MINI	Through Hole	-25 °C	85 °C	Board Mount	Vented Gauge	Wheatstone Bridge	60 mV			1 %	16 VDC	4-SIP Module	PC Pin	Temperature Compensated	Barbless	137.9 kPa	20 PSI			34.47 kPa	5 PSI	12V
Amphenol All Sensors Corporation 10 INCH-GF-CGRADE-MINI	Through Hole	-25 °C	85 °C	Board Mount	Vented Gauge	Wheatstone Bridge	20 mV			1 %	16 VDC	4-SIP Module	PC Pin	Temperature Compensated	Barbless	137.9 kPa	20 PSI			2.49 kPa	0.36 PSI
Amphenol All Sensors Corporation 15 PSI-GF-CGRADE-MINI	Through Hole	-25 °C	85 °C	Board Mount	Vented Gauge	Wheatstone Bridge	90 mV			1 %	16 VDC	4-SIP Module	PC Pin	Temperature Compensated	Barbless								15 PSI	103.42 kPa	60 PSI	413.69 kPa

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tube	1	$ 42.00
		10	$ 31.50
		25	$ 31.32
		100	$ 28.00

Description

General part information

GF-CGRADE-MINI Series

Pressure Sensor 5PSI (34.47kPa) Vented Gauge Male - 0.18" (4.57mm) Tube 0 mV ~ 60 mV (12V) 4-SIP Module
