Specification	1812J1000123MXTE03

Applications	Bypass, Decoupling
Capacitance	0.012 µF
Features	Low ESL (X2Y)
Height (Max)	0.03 in
Mounting Type	Surface Mount, MLCC
Operating Temperature (Max)	125 °C
Operating Temperature (Min)	-55 °C
Package / Case	1812 (4532 Metric)
Size / Dimension Length	0.177 in
Size / Dimension Width	0.126 in
Temperature Coefficient	X7R
Thickness (Max)	0.03 in
Tolerance	20 %
Voltage - Rated	100 VAC/DC

1812J Series

...

Part	Features	Temperature Coefficient	Applications	Thickness (Max)	Package / Case	Capacitance	Voltage - Rated	Size / Dimension Length	Size / Dimension Width	Tolerance	Operating Temperature (Max)	Operating Temperature (Min)	Ratings	Mounting Type
Knowles Syfer 1812JA250471JXTPY2	High Voltage	X7R	Safety	0.098 in	1812 (4532 Metric)	470 pF	250 V	0.177 in	0.126 in	5 %	125 °C	-55 °C	X1	MLCC Surface Mount
Knowles Syfer 1812J0160682KXT		X7R	General Purpose	0.098 in	1812 (4532 Metric)	6800 pF	16 V	0.177 in	0.126 in	10 %	125 °C	-55 °C		MLCC Surface Mount
Knowles Syfer 1812J6300272KXT		X7R	General Purpose	0.098 in	1812 (4532 Metric)	2700 pF	630 V	0.177 in	0.126 in	10 %	125 °C	-55 °C		MLCC Surface Mount
Knowles Syfer 1812J2000220GFT	High Temperature	C0G NP0	High Reliability	0.098 in	1812 (4532 Metric)	22 pF	200 VDC	0.177 in	0.126 in	2 %	125 °C	-55 °C		MLCC Surface Mount
Knowles Syfer 1812J2K00391JCT		C0G NP0 (1B)	General Purpose	0.098 in	1812 (4532 Metric)	390 pF	2000 VAC	0.177 in	0.126 in	5 %	125 °C	-55 °C		MLCC Surface Mount
Knowles Syfer 1812J6300151GCT		C0G NP0 (1B)	General Purpose	0.098 in	1812 (4532 Metric)	150 pF	630 V	0.177 in	0.126 in	2 %	125 °C	-55 °C		MLCC Surface Mount
Knowles Syfer 1812J0630154KDT	High Temperature	X7R	High Reliability	0.098 in	1812 (4532 Metric)	0.15 µF	63 V	0.177 in	0.126 in	10 %	125 °C	-55 °C		MLCC Surface Mount
Knowles Syfer 1812J1K50122KXT		X7R	General Purpose	0.098 in	1812 (4532 Metric)	1200 pF	1500 VAC	0.177 in	0.126 in	10 %	125 °C	-55 °C		MLCC Surface Mount
Knowles Syfer 1812J0630180KFT	High Temperature	C0G NP0	High Reliability	0.098 in	1812 (4532 Metric)	18 pF	63 V	0.177 in	0.126 in	10 %	125 °C	-55 °C		MLCC Surface Mount
Knowles Syfer 1812J1000121KFT	High Temperature	C0G NP0	High Reliability	0.098 in	1812 (4532 Metric)	120 pF	100 VAC/DC	0.177 in	0.126 in	10 %	125 °C	-55 °C		MLCC Surface Mount
