DS1250WP-100IND+

Active

Analog Devices Inc./Maxim Integrated

IC NVSRAM 4MBIT PAR 34PWRCAP

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

DS1250WP-100IND+

Active

Analog Devices Inc./Maxim Integrated

IC NVSRAM 4MBIT PAR 34PWRCAP

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	DS1250WP-100IND+	DS1250W Series

Access Time	100 ns	100 - 150 ns
Memory Format	NVSRAM	NVSRAM
Memory Interface	Parallel	Parallel
Memory Organization	512 K	512 K
Memory Size	512 kb	512 kb
Memory Type	Non-Volatile	Non-Volatile
Mounting Type	Surface Mount	Through Hole, Surface Mount
Operating Temperature [Max]	85 °C	70 - 85 °C
Operating Temperature [Min]	-40 °C	-40 - 0 °C
Package / Case	34-PowerCap™ Module	32-DIP Module, 34-PowerCap™ Module
Package / Case	-	0.6 in
Package / Case	-	15.24 mm
Supplier Device Package	34-PowerCap Module	32-EDIP, 34-PowerCap Module
Technology	NVSRAM (Non-Volatile SRAM)	NVSRAM (Non-Volatile SRAM)
Voltage - Supply [Max]	3.6 V	3.6 V
Voltage - Supply [Min]	3 V	3 V
Write Cycle Time - Word, Page	-	150 ns
Write Cycle Time - Word, Page [custom]	100 ns	100 ns
Write Cycle Time - Word, Page [custom]	100 ns	100 ns

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

DS1250W Series

IC NVSRAM 4MBIT PARALLEL 32EDIP

Part	Memory Format	Memory Size	Voltage - Supply [Max]	Voltage - Supply [Min]	Memory Organization	Access Time	Memory Type	Technology	Operating Temperature [Max]	Operating Temperature [Min]	Package / Case	Package / Case	Package / Case	Write Cycle Time - Word, Page [custom]	Write Cycle Time - Word, Page [custom]	Supplier Device Package	Mounting Type	Memory Interface	Write Cycle Time - Word, Page
Analog Devices Inc./Maxim Integrated DS1250W-100IND	NVSRAM	512 kb	3.6 V	3 V	512 K	100 ns	Non-Volatile	NVSRAM (Non-Volatile SRAM)	85 °C	-40 °C	0.6 in	15.24 mm	32-DIP Module	100 ns	100 ns	32-EDIP	Through Hole	Parallel
Analog Devices Inc./Maxim Integrated DS1250W-150+	NVSRAM	512 kb	3.6 V	3 V	512 K	150 ns	Non-Volatile	NVSRAM (Non-Volatile SRAM)	70 °C	0 °C	0.6 in	15.24 mm	32-DIP Module			32-EDIP	Through Hole	Parallel	150 ns
Analog Devices Inc./Maxim Integrated DS1250W-100+	NVSRAM	512 kb	3.6 V	3 V	512 K	100 ns	Non-Volatile	NVSRAM (Non-Volatile SRAM)	70 °C	0 °C	0.6 in	15.24 mm	32-DIP Module	100 ns	100 ns	32-EDIP	Through Hole	Parallel
Analog Devices Inc./Maxim Integrated DS1250WP-100+	NVSRAM	512 kb	3.6 V	3 V	512 K	100 ns	Non-Volatile	NVSRAM (Non-Volatile SRAM)	70 °C	0 °C			34-PowerCap™ Module	100 ns	100 ns	34-PowerCap Module	Surface Mount	Parallel
Analog Devices Inc./Maxim Integrated DS1250WP-100IND+	NVSRAM	512 kb	3.6 V	3 V	512 K	100 ns	Non-Volatile	NVSRAM (Non-Volatile SRAM)	85 °C	-40 °C			34-PowerCap™ Module	100 ns	100 ns	34-PowerCap Module	Surface Mount	Parallel
Analog Devices Inc./Maxim Integrated DS1250W-100IND+	NVSRAM	512 kb	3.6 V	3 V	512 K	100 ns	Non-Volatile	NVSRAM (Non-Volatile SRAM)	85 °C	-40 °C	0.6 in	15.24 mm	32-DIP Module	100 ns	100 ns	32-EDIP	Through Hole	Parallel
Analog Devices Inc./Maxim Integrated DS1250WP-150	NVSRAM	512 kb	3.6 V	3 V	512 K	150 ns	Non-Volatile	NVSRAM (Non-Volatile SRAM)	70 °C	0 °C			34-PowerCap™ Module			34-PowerCap Module	Surface Mount	Parallel	150 ns

Description

General part information

DS1250W Series

NVSRAM (Non-Volatile SRAM) Memory IC 4Mbit Parallel 100 ns 34-PowerCap Module
