B82144F1106J000
ActiveEPCOS - TDK Electronics
FIXED IND 10MH 85MA 42OHM TH
B82144F1106J000
ActiveEPCOS - TDK Electronics
FIXED IND 10MH 85MA 42OHM TH
Description
General part information
B82144F1106J000
10 mH Unshielded Drum Core, Wirewound Inductor 85 mA 42Ohm Max Axial
Technical Specifications
Parameters and characteristics for this part
| Specification | B82144F1106J000 |
|---|---|
| Current Rating | 85 mA |
| DC Resistance (DCR) (Max) | 42 Ohm |
| Frequency - Self Resonant | 750 kHz |
| Inductance | 10 mH |
| Inductance Frequency - Test | 100 kHz |
| Material - Core | Ferrite |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | Axial |
| Q | 50 |
| Shielding | Unshielded |
| Size / Dimension Diameter | 0.256 in |
| Size / Dimension Length | 0.362 in |
| Tolerance | 5 % |
| Type | Drum Core, Wirewound |
