FN2060A-3-06

Active

TE Connectivity Raychem Cable Protection

LINE FILTER 250VAC 3A CHASSIS

Search across all available documentation for this part.

Active

TE Connectivity Raychem Cable Protection

LINE FILTER 250VAC 3A CHASSIS

Technical Specifications

Parameters and characteristics for this part

Specification	FN2060A-3-06

Applications	Safety
Approval Agency	UR, CSA, ENEC, CE
Configuration	Two Stage
Current	3 A
Filter Type	Single Phase
Frequency - Operating	400 Hz
Inductance	2.5 mH
Mounting Type	Chassis Mount
Operating Temperature [custom]	100 °C, -25 °C
Termination Style	Quick Connect
Voltage - Rated AC	250 V

Part	Filter Type	Termination Style	Voltage - Rated AC	Operating Temperature [custom]	Configuration	Applications	Frequency - Operating	Mounting Type	Approval Agency	Inductance	Current
TE Connectivity Raychem Cable Protection FN2060A-3-06	Single Phase	Quick Connect	250 V	-25 °C 100 °C	Two Stage	Safety	400 Hz	Chassis Mount	CE CSA ENEC UR	2.5 mH	3 A
TE Connectivity Raychem Cable Protection FN2060A-20-08	Single Phase	Threaded Post (M4)	250 V	-25 °C 100 °C	Two Stage	Safety	400 Hz	Chassis Mount	CE CSA ENEC UR	600 µH	20 A
TE Connectivity Raychem Cable Protection FN2060A-6-06	Single Phase	Quick Connect	250 V	-25 °C 100 °C	Two Stage	Safety	400 Hz	Chassis Mount	CE CSA ENEC UR	970 µH	6 A
TE Connectivity Raychem Cable Protection FN2060A-30-08	Single Phase	Threaded Post (M4)	250 V	-25 °C 100 °C	Two Stage	Safety	400 Hz	Chassis Mount	CE CSA ENEC UR	600 µH	30 A

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Single Phase EMC/EMI Line Filter 3 A 250V DC ~ 400Hz Two Stage Quick Connect
