AM10G-1209NZ

Obsolete

aimtec

DC DC CONVERTER 9V 10W

Search across all available documentation for this part.

Obsolete

aimtec

DC DC CONVERTER 9V 10W

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tube	1	$ 16.49

General part information

Isolated Module DC DC Converter 1 Output 9V 1.11A 9V - 18V Input

Technical documentation and resources

Parameters and characteristics commom to parts in this series

DC DC CONVERTER 9V 10W

Part	Voltage - Output 1	Operating Temperature [Max]	Operating Temperature [Min]	Efficiency	Package / Case	Power (Watts)	Mounting Type	Voltage - Isolation	Features	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Applications	Current - Output (Max) [Max]	Voltage - Input (Min) [Min]	Voltage - Input (Max) [Max]	Number of Outputs	Type	Package / Case	Control Features
aimtec AM10G-2409NZ	9 V	85 °C	-40 °C	86 %	8-SIP Module	10 W	Through Hole	1.5 kV	Remote On/Off	0.47 "	22 mm	0.37 "	0.87 in	9.5 mm	12 mm	ITE (Commercial)	1.11 A	18 V	36 V	1	Isolated Module
aimtec AM10GH-2409NZ	9 V	85 °C	-40 °C	86 %	8-SIP Module	10 W	Through Hole	1.5 kV	Remote On/Off	0.47 "	22 mm	0.37 "	0.87 in	9.5 mm	12 mm	ITE (Commercial)	1.11 A	9 V	36 V	1	Isolated Module	7 Leads	Active Low, Enable
aimtec AM10G-1224NZ	24 V	85 °C	-40 °C	84 %	8-SIP Module	10 W	Through Hole	1.5 kV	Remote On/Off	0.47 "	22 mm	0.37 "	0.87 in	9.5 mm	12 mm	ITE (Commercial)	420 mA	9 V	18 V	1	Isolated Module
aimtec AM10G-1205NZ	5 V	85 °C	-40 °C	84 %	8-SIP Module	10 W	Through Hole	1.5 kV	Remote On/Off	0.47 "	22 mm	0.37 "	0.87 in	9.5 mm	12 mm	ITE (Commercial)	2 A	9 V	18 V	1	Isolated Module
aimtec AM10G-1209NZ	9 V	85 °C	-40 °C	84 %	8-SIP Module	10 W	Through Hole	1.5 kV	Remote On/Off	0.47 "	22 mm	0.37 "	0.87 in	9.5 mm	12 mm	ITE (Commercial)	1.11 A	9 V	18 V	1	Isolated Module
