DT62PW120C
ObsoleteTDK Corporation
AC/DC DESKTOP ADAPTER 12V 62W
DT62PW120C
ObsoleteTDK Corporation
AC/DC DESKTOP ADAPTER 12V 62W
Description
General part information
DT62PW120C
12V 62 W AC/DC External Desktop (Class I) Adapter Cord (Sold Separately) Input
Technical Specifications
Parameters and characteristics for this part
| Specification | DT62PW120C |
|---|---|
| Applications | ITE (Commercial) |
| Cord Length | 41.34 in |
| Current - Output (Max) | 5.17 A |
| Efficiency | Level V |
| Form | Desktop (Class I) |
| Input Connector | IEC 320-C14 |
| Input Type | Cord (Sold Separately) |
| Operating Temperature (Max) | 40 °C |
| Operating Temperature (Min) | 0 °C |
| Output Connector | 4 Pin, Power DIN |
| Power (Watts) | 62 W |
| Region Utilized | International |
| Size / Dimension Height | 1.57 in |
| Size / Dimension Length | 5.2 in |
| Size / Dimension Width | 2.71 in |
| Voltage - Input (AC) Maximum | 264 V |
| Voltage - Input (AC) Minimum | 90 V |
| Voltage - Output | 12 V |
| Weight | 0.904 lb |
