Description
General part information
COM-11448
Red, Green, Blue (RGB) LED Indication - Discrete 4.5V Radial
Technical Specifications
Parameters and characteristics for this part
| Specification | COM-11448 |
|---|---|
| Color | Blue (RGB), Green, Red |
| Configuration | Common Cathode |
| Current - Test (Blue) | 20 mA |
| Current - Test (Green) | 20 mA |
| Current - Test (Red) | 20 mA |
| Current - Test Colors | Red, Blue, Green |
| Features | Cycling (Slow) |
| Height (Max) | 8.9 mm |
| Lens Color | Colorless |
| Lens Size | 3 mm |
| Lens Size (Code) | T-1 |
| Lens Style | Round, Domed Top |
| Lens Transparency | Clear |
| Millicandela Rating (Blue) | 1200 mcd |
| Millicandela Rating (Green) | 1500 mcd |
| Millicandela Rating (Red) | 1000 mcd |
| Millicandela Rating Colors | Blue, Green, Red |
| Mounting Type | Through Hole |
| Package / Case | Radial |
| Voltage - Forward (Vf) (Typ) | 4.5 V |
| Wavelength - Peak (Blue) | 460 nm |
| Wavelength - Peak (Green) | 515 nm |
| Wavelength - Peak (Red) | 620 nm |
| Wavelength - Peak Colors | Green, Red, Blue |
