PH150F280-12
ObsoleteTDK Corporation
DC DC CONVERTER 12V 150W
PH150F280-12
ObsoleteTDK Corporation
DC DC CONVERTER 12V 150W
Description
General part information
PH150F280-12
Isolated Module DC DC Converter 1 Output 12V 12.5A 200V - 400V Input
Technical Specifications
Parameters and characteristics for this part
| Specification | PH150F280-12 |
|---|---|
| Applications | ITE (Commercial) |
| Control Features | Enable, Active Low |
| Current - Output (Max) | 12.5 A |
| Features | OCP, OVP, Remote On/Off |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -20 °C |
| Package / Case | Module |
| Power (Watts) | 150 W |
| Size / Dimension Height | 0.5 in |
| Size / Dimension Length | 3.39 in |
| Size / Dimension Width | 2.83 in |
| Type | Isolated Module |
| Voltage - Input (Max) | 400 VDC |
| Voltage - Input (Min) | 200 VAC |
| Voltage - Isolation | 3 kV |
| Voltage - Output 1 | 12 V |
