LZ2H2X43FU
ActiveSCHNEIDER ELECTRIC
MOTOR STARTER, REVERSING, TESYS H SERIES, THREE PHASE, 1.1 KW, 500 VAC, 10 TO 230 VAC COIL
LZ2H2X43FU
ActiveSCHNEIDER ELECTRIC
MOTOR STARTER, REVERSING, TESYS H SERIES, THREE PHASE, 1.1 KW, 500 VAC, 10 TO 230 VAC COIL
Description
General part information
LZ2H2X43FU
Motor Starter, Reversible 110 ~ 230VAC Supply 2.4A 500V Load
Technical Specifications
Parameters and characteristics for this part
| Specification | LZ2H2X43FU |
|---|---|
| Control / Drive Type | Motor Starter, Reversible |
| Current - Output | 2.4 A |
| Motor Type | AC Motor |
| Mounting Type | DIN Rail |
| Number of Motors | 1 |
| Operating Temperature (Max) | 70 °C |
| Operating Temperature (Min) | -25 °C |
| Type | Module |
| Voltage - Load | 500 V |
| Voltage - Supply (Maximum) | 230 VAC |
| Voltage - Supply (Minimum) | 110 VAC |
| Wattage - Load | 1.1 kW |
