LP1K1210FD
ActiveSCHNEIDER ELECTRIC
3P CONTACTOR 12A AC3 5.5KW 110VD
LP1K1210FD
ActiveSCHNEIDER ELECTRIC
3P CONTACTOR 12A AC3 5.5KW 110VD
Description
General part information
LP1K1210FD
3P CONTACTOR 12A AC3 5.5KW 110VD
Technical Specifications
Parameters and characteristics for this part
| Specification | LP1K1210FD |
|---|---|
| Coil Voltage | 110 V |
| Contact Form | A, PST-NO, Form, 3 |
| Contact Rating (Current) | 12 A |
| Features | Auxiliary Contacts |
| Mounting Type | Chassis Mount, DIN Rail |
| Must Operate Voltage | 88 V |
| Must Release Voltage | 11 VDC |
| Operate Time | 10 ms |
| Operating Temperature (Max) | 50 °C |
| Operating Temperature (Min) | -25 °C |
| Pin Count | 3 pins |
| Release Time | 40 ms |
| Switching Voltage AC (Max) | 690 VAC |
| Termination Style | Screw Terminal |
