STE470-75T3MI
ActiveVishay Dale
CAP TANT WET 470UF 75V 20%( 10.31 X 21.09MM) AXIAL 0.6 OHM 125°C TRAY
STE470-75T3MI
ActiveVishay Dale
CAP TANT WET 470UF 75V 20%( 10.31 X 21.09MM) AXIAL 0.6 OHM 125°C TRAY
Description
General part information
STE470-75T3MI
470 µF Hermetically Sealed Tantalum Capacitors 75 V Axial 600mOhm @ 120Hz
Technical Specifications
Parameters and characteristics for this part
| Specification | STE470-75T3MI |
|---|---|
| Capacitance | 470 µF |
| ESR (Equivalent Series Resistance) | 600 mOhm |
| Features | Wet Tantalum |
| Manufacturer Size Code | T3 |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | Axial |
| Size / Dimension Diameter | 0.406 in |
| Size / Dimension Length | 0.766 in |
| Tolerance | 20 % |
| Type | Hermetically Sealed |
| Voltage - Rated | 75 V |
