76-IRT8-1/4C
ActiveNTE Electronics, Inc
PVC INS RING TERM 8AWG 100 BAG
76-IRT8-1/4C
ActiveNTE Electronics, Inc
PVC INS RING TERM 8AWG 100 BAG
Description
General part information
76-IRT8-1/4C
Ring Terminal Connector 1/4 Stud Circular 8 AWG Crimp
Technical Specifications
Parameters and characteristics for this part
| Specification | 76-IRT8-1/4C |
|---|---|
| Color | White |
| Contact Finish | Electro-Tin |
| Contact Material | Copper |
| Insulation | Insulated |
| Length - Overall | 1.28 in |
| Material - Insulation | PVC, Poly-Vinyl Chloride |
| Mounting Type | Free Hanging (In-Line) |
| Stud/Tab Size | 0.25 Stud |
| Terminal Type | Circular |
| Termination | Crimp |
| Width - Outer Edges | 0.472 in |
| Wire Gauge | 8 AWG |
