Specification	D38999/26KJ90SN

Applications	Military, Aviation, Marine, Aerospace
Connector Type	Female Sockets, Plug
Contact Finish - Mating	Gold
Contact Finish Thickness - Mating	50 µin
Contact Material	Copper Alloy
Current Rating Options	45A, 7.5A, 13A
Fastening Type	Threaded
Features	Self Locking, Coupling Nut
Grade	Military
Ingress Protection	Weathertight
Ingress Protection Description	Waterproof, Dust Tight
Ingress Protection IP Rating	IP67
Insert Material	Thermoplastic
Material Flammability Rating	UL94 V-0
Mounting Type	Free Hanging (In-Line)
Number of Positions	46, 65
Operating Temperature (Max)	200 °C, 150 °C
Operating Temperature (Min)	-65 °C
Orientation	N (Normal)
Position Types	Triax
Primary Material	Metal
Qualification	MIL-DTL-38999 Series II
Shell Finish	Passivated
Shell Material	Stainless Steel
Shell Size - Insert (Maximum)	90
Shell Size - Insert (Minimum)	25
Shell Size (MIL)	J
Shielding	Shielded
Termination	Crimp
Voltage Rating	500 V

D38999/26KJ Series

Part	Mounting Type	Shell Finish	Connector Type	Contact Size	Type	Contact Shape	Shell Material	Housing Color	Note	Shell Size - Insert (Minimum)	Shell Size - Insert (Maximum)	Contact Type	Number of Positions	Fastening Type	Orientation	Shielding	Operating Temperature (Max)	Operating Temperature (Min)	Features	Ingress Protection Description	Ingress Protection IP Rating	Insert Material	Shell Size (MIL)	Applications	Termination	Contact Finish - Mating	Contact Finish Thickness - Mating	Primary Material	Contact Material	Current Rating	Shell Size - Insert Width	Shell Size - Insert Length	Qualification	Ingress Protection	Grade
Amphenol Aerospace Operations D38999/26KJ43AD	Free Hanging (In-Line)	Passivated	Plug Housing	16 20	For Male Pins	Circular	Stainless Steel	Silver	Contacts Not Included	25	43	Crimp	43	Threaded	D	Shielded	200 °C	-65 °C	Coupling Nut Firewall Usage	Dust Tight Waterproof	IP67	Thermoplastic	J
Amphenol Aerospace Operations D38999/26KJ29SNL
Amphenol Aerospace Operations D38999/26KJ35HN	Free Hanging (In-Line)		Male Pins Plug							25	35		128	Threaded	N (Normal)	Shielded							J	Aerospace Aviation Military	Crimp	Gold
Amphenol Aerospace Operations D38999/26KJ35PN	Free Hanging (In-Line)	Passivated	Male Pins Plug				Stainless Steel			25	35		128	Threaded	N (Normal)	Shielded	200 °C	-65 °C	Coupling Nut	Dust Tight Waterproof	IP67	Thermoplastic	J	Aviation Marine Military	Crimp	Gold	50 µin	Metal	Copper Alloy	5 A
Amphenol Aerospace Operations D38999/26KJ37BD	Free Hanging (In-Line)	Passivated	Plug Housing	16 S	For Female Sockets	Circular	Stainless Steel	Silver	Contacts Not Included	25	37	Crimp	37 pos	Threaded	D	Shielded	200 °C	-65 °C	Coupling Nut Firewall Usage	Dust Tight Waterproof	IP67	Thermoplastic	J
Amphenol Aerospace Operations D38999/26KJ19AD
Amphenol Aerospace Operations D38999/26KJ35PNL
Amphenol Aerospace Operations D38999/26KJ43AD
Amphenol Aerospace Operations D38999/26KJ11AD	Free Hanging (In-Line)	Passivated	Plug Housing	10 20	For Male Pins	Circular	Stainless Steel	Silver	Contacts Not Included			Crimp	11	Threaded	D	Shielded	200 °C	-65 °C	Coupling Nut Firewall Usage	Dust Tight Waterproof	IP67	Thermoplastic	J								11 mm	25 mm
Amphenol Aerospace Operations D38999/26KJ37AN	Free Hanging (In-Line)	Passivated	Plug Housing	16 S	For Male Pins	Circular	Stainless Steel	Silver	Contacts Not Included	25	37	Crimp	37 pos	Threaded	N (Normal)	Shielded	200 °C	-65 °C	Coupling Nut Firewall Usage Self Locking				J										MIL-DTL-38999 Series III	Environment Resistant	Military
