2770286
LTBPhoenix Contact
TERM BLK PLUG 4POS 5.08MM BLUE
2770286
LTBPhoenix Contact
TERM BLK PLUG 4POS 5.08MM BLUE
Description
General part information
2770286
4 Position Terminal Block Blue Plug Connection 5.1mm
Technical Specifications
Parameters and characteristics for this part
| Specification | 2770286 |
|---|---|
| Current - IEC | 12 A |
| Current - UL | 10 A |
| Height (Max) | 2.402 in |
| Housing Color | Blue |
| Length | 1.969 in |
| Material - Insulation | Polyamide, PA, Nylon |
| Material Flammability Rating | UL94 V-2 |
| Mounting Type | DIN Rail |
| Number of Levels | 2 |
| Number of Positions | 4 |
| Stripping Length | 8 mm |
| Terminal Width | 5.1 mm |
| Termination Style | Screw, Plug Receptacles |
| Type | Plug Connection |
| Voltage - IEC | 250 V |
| Voltage - UL | 300 V |
| Wire Gauge or Range - AWG (Max) | 30 AWG |
| Wire Gauge or Range - AWG (Min) | 12 AWG |
| Wire Gauge or Range - mm² (Maximum) | 4 mm² |
| Wire Gauge or Range - mm² (Minimum) | 0.2 mm² |
