FFV34F0556K--
ActiveKYOCERA AVX
CAP FILM 55UF 10% 160VDC RADIAL
FFV34F0556K--
ActiveKYOCERA AVX
CAP FILM 55UF 10% 160VDC RADIAL
Description
General part information
FFV34F0556K--
55 µF Film Capacitor 75V 160V Polyester, Metallized Radial - 4 Leads
Technical Specifications
Parameters and characteristics for this part
| Specification | FFV34F0556K-- |
|---|---|
| Applications | General Purpose |
| Capacitance | 55 µF |
| Dielectric Material | Polyester, Metallized |
| Height - Seated (Max) | 1.575 in |
| Lead Spacing | 0.984 in |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 105 °C |
| Operating Temperature (Min) | -40 °C |
| Package Leads | 4 Leads |
| Package Name | Radial |
| Size / Dimension Length | 1.575 in |
| Size / Dimension Width | 1.417 in |
| Termination | PC Pins |
| Tolerance | 10 % |
| Voltage Rating - AC | 75 V |
| Voltage Rating - DC | 160 V |
