B82473M1683K000
ActiveEPCOS - TDK Electronics
FIXED IND 68UH 850MA 280MOHM SMD
B82473M1683K000
ActiveEPCOS - TDK Electronics
FIXED IND 68UH 850MA 280MOHM SMD
Description
General part information
B82473M1683K000
68 µH Unshielded Drum Core, Wirewound Inductor 850 mA 280mOhm Max Nonstandard
Technical Specifications
Parameters and characteristics for this part
| Specification | B82473M1683K000 |
|---|---|
| Current - Saturation (Isat) | 0.9 mA |
| Current Rating | 0.85 A |
| DC Resistance (DCR) (Max) | 280 mOhm |
| Height - Seated (Max) | 0.217 in |
| Inductance | 68 µH |
| Inductance Frequency - Test | 100 kHz |
| Material - Core | Ferrite |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 150 °C |
| Operating Temperature (Min) | -50 °C |
| Package / Case | Nonstandard |
| Ratings | AEC-Q200 |
| Shielding | Unshielded |
| Size / Dimension Length | 0.327 in |
| Size / Dimension Width | 0.287 in |
| Tolerance | 10 % |
| Type | Drum Core, Wirewound |
