Description
General part information
VDRS-100-15
DIN RAIL POWER SUPPLIES AC-DC, 100 W, 15 VDC, SINGLE OUTPUT, DIN RAIL
Technical Specifications
Parameters and characteristics for this part
| Specification | VDRS-100-15 |
|---|---|
| AC Voltage - Input (Max) | 264 VAC |
| AC Voltage - Input (Min) | 88 VAC |
| Applications | ITE (Commercial) |
| Approval Agency | TUV, cULus, CE, cURus |
| Current - Output (Max) | 6.4 A |
| Efficiency | 87 % |
| Features | Universal Input, Adjustable Output |
| Input Type | AC |
| Number of Outputs | 1 |
| Operating Temperature (Max) | 70 °C |
| Operating Temperature (Min) | -20 °C |
| Power (Watts) | 100 W |
| Size / Dimension Height | 3.54 in |
| Size / Dimension Length | 3.9 in |
| Size / Dimension Width | 2.17 in |
| Voltage - Isolation | 3 kV |
| Voltage - Output 1 | 15 V |
