B78108S1103K009
LTBEPCOS - TDK Electronics
FIXED IND 10UH 680MA 490 MOHM TH
B78108S1103K009
LTBEPCOS - TDK Electronics
FIXED IND 10UH 680MA 490 MOHM TH
Description
General part information
B78108S1103K009
10 µH Unshielded Drum Core, Wirewound Inductor 680 mA 490mOhm Max Axial
Technical Specifications
Parameters and characteristics for this part
| Specification | B78108S1103K009 |
|---|---|
| Current Rating | 0.68 A |
| DC Resistance (DCR) (Max) | 490 mOhm |
| Frequency - Self Resonant | 35 MHz |
| Inductance | 10 µH |
| Inductance Frequency - Test | 2.52 MHz |
| Material - Core | Ferrite |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | Axial |
| Q | 70 |
| Shielding | Unshielded |
| Size / Dimension Diameter | 0.157 in |
| Size / Dimension Length | 0.362 in |
| Tolerance | 10 % |
| Type | Drum Core, Wirewound |
