MAX11168EVKIT#
ActiveAnalog Devices Inc./Maxim Integrated
EVALUATION KIT FOR 16-BIT, 500KS
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
MAX11168EVKIT#
ActiveAnalog Devices Inc./Maxim Integrated
EVALUATION KIT FOR 16-BIT, 500KS
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | MAX11168EVKIT# | MAX11168 Series |
|---|---|---|
| Architecture | - | SAR |
| Configuration | - | S/H-ADC |
| Data Interface | SPI | SPI, DSP |
| Input Range | ±VREF | ±VREF |
| Input Type | - | Pseudo-Differential |
| Mounting Type | - | Surface Mount |
| Number of A/D Converters | 1 | 1 |
| Number of Bits | 16 | 16 |
| Number of Inputs | - | 1 |
| Operating Temperature | - | 85 °C |
| Operating Temperature | - | -40 °C |
| Package / Case | - | 10-MSOP, 10-TFSOP |
| Package / Case | - | 3 mm |
| Package / Case | - | 0.118 in |
| Power (Typ) @ Conditions | 37.6 mW | 37.6 mW |
| Ratio - S/H:ADC | - | 1:1 |
| Reference Type | - | Internal |
| Sampling Rate (Per Second) | 500k | 500k |
| Supplied Contents | Board(s) | Board(s) |
| Supplier Device Package | - | 10-uMAX/uSOP |
| Utilized IC / Part | MAX11168 | MAX11168 |
| Voltage - Supply, Analog | - | 5 V |
| Voltage - Supply, Digital | - | 2.3 V |
| Voltage - Supply, Digital | - | 5 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 120.12 | |
MAX11168 Series
EVALUATION KIT FOR 16-BIT, 500KS
| Part | Sampling Rate (Per Second) | Data Interface | Number of Bits | Utilized IC / Part | Input Range | Power (Typ) @ Conditions | Supplied Contents | Number of A/D Converters | Supplier Device Package | Ratio - S/H:ADC | Configuration | Number of Inputs | Input Type | Voltage - Supply, Analog | Voltage - Supply, Digital [Min] | Voltage - Supply, Digital [Max] | Operating Temperature [Max] | Operating Temperature [Min] | Mounting Type | Architecture | Package / Case | Package / Case [x] | Package / Case [x] | Reference Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Analog Devices Inc./Maxim Integrated MAX11168EVKIT# | 500k | SPI | 16 | MAX11168 | ±VREF | 37.6 mW | Board(s) | 1 | ||||||||||||||||
Analog Devices Inc./Maxim Integrated MAX11168EUB+ | 500k | DSP, SPI | 16 | 1 | 10-uMAX/uSOP | 1:1 | S/H-ADC | 1 | Pseudo-Differential | 5 V | 2.3 V | 5 V | 85 °C | -40 °C | Surface Mount | SAR | 10-MSOP, 10-TFSOP | 3 mm | 0.118 in | Internal | ||||
Analog Devices Inc./Maxim Integrated MAX11168EUB+T | 500k | DSP, SPI | 16 | 1 | 10-uMAX/uSOP | 1:1 | S/H-ADC | 1 | Pseudo-Differential | 5 V | 2.3 V | 5 V | 85 °C | -40 °C | Surface Mount | SAR | 10-MSOP, 10-TFSOP | 3 mm | 0.118 in | Internal |
Description
General part information
MAX11168 Series
MAX11168 - 16 Bit 500k Samples per Second Analog to Digital Converter (ADC) Evaluation Board
