ZA9423-33NMED
33 nH Unshielded Wirewound Inductor 30.2 A 0.62mOhm Max 3-SMD, Gull Wing
Technical Specifications
Parameters and characteristics for this part
| Specification | ZA9423-33NMED |
|---|---|
| Current Rating | 30.2 A |
| DC Resistance (DCR) (Max) | 0.62 mOhm |
| Frequency - Self Resonant | 817 MHz |
| Height - Seated (Max) | 0.25 in |
| Inductance | 33 nH |
| Inductance Frequency - Test | 1 MHz |
| Material - Core | Air |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Gull Wing, 3-SMD |
| Package Name | 3-SMD |
| Q | 456 |
| Shielding | Unshielded |
| Size / Dimension Length | 0.583 in |
| Size / Dimension Width | 0.776 in |
| Tolerance | 20 % |
| Type | Wirewound |
