Specification	TOL-19898

Applications	ITE (Commercial)
Approval Agency	CE, UKCA
Barrel Plug Diameter (0.7mm x 2.5mm)	0.7 mm
Barrel Plug Diameter (1.35mm x 3.5mm)	1.35 mm
Barrel Plug Diameter (1.7mm x 4.8mm)	1.7 mm
Barrel Plug Diameter (1.7mm x 4mm)	1.7 mm
Barrel Plug Diameter (1mm x 3mm)	1 mm
Barrel Plug Diameter (2.1mm x 5.5mm)	2.1 mm
Barrel Plug Diameter (2.5mm x 5.5mm)	2.5 mm
Barrel Plug Length (0.7mm x 2.5mm)	2.5 mm
Barrel Plug Length (1.35mm x 3.5mm)	3.5 mm
Barrel Plug Length (1.7mm x 4.8mm)	4.8 mm
Barrel Plug Length (1.7mm x 4mm)	4 mm
Barrel Plug Length (1mm x 3mm)	3 mm
Barrel Plug Length (2.1mm x 5.5mm)	5.5 mm
Barrel Plug Length (2.5mm x 5.5mm)	5.5 mm
Cord Length	56 in
Current - Output (Max)	3 A
Efficiency	Level VI
Form	Wall Mount (Class II)
Input Connector	NEMA 1-15P
Input Type	Fixed Blade
Output Connector	USB A Receptacle, Barrel Plug Kit, USB Micro
Polarization	Positive Center
Power (Watts)	45 W
Region Utilized	North America
Voltage - Input (AC) Maximum	240 VAC
Voltage - Input (AC) Minimum	100 VAC
Voltage - Output	6V, 13.5V, 12V, 7.5V, 9V, 15V, 5V
Voltage - Output	12 V, 7.5 V, 13.5 V, 15 V, 6 V, 9 V, 5 VDC
Voltage - Output (1)	5 V
Voltage - Output (2)	6 V
Voltage - Output (3)	7.5 V
Voltage - Output (4)	9 V
Voltage - Output (5)	12 V
Voltage - Output (6)	13.5 V
Voltage - Output (7)	15 V
