Specification	B43601E2128M000

Applications	General Purpose
Capacitance	1200 µF
ESR (Equivalent Series Resistance)	75 mOhm
Height - Seated (Max)	1.85 in
Impedance	110 mOhm
Lead Spacing	0.394 in
Lifetime	10000 Hrs
Mounting Type	Through Hole
Operating Temperature (Max)	85 °C
Operating Temperature (Min)	-40 °C
Package / Case	Can - Snap-In, Radial
Polarization	Polar
Ripple Current	3.56 A
Size / Dimension Diameter	1.181 in
Tolerance	20 %
Voltage - Rated	250 V
