9007MS04G0500
ActiveSCHNEIDER ELECTRIC
LIMIT SWITCH, IP20, ROTARY, SPDT, 100 MA, 125 V, 48 IN-OZ, 9007 SERIES
9007MS04G0500
ActiveSCHNEIDER ELECTRIC
LIMIT SWITCH, IP20, ROTARY, SPDT, 100 MA, 125 V, 48 IN-OZ, 9007 SERIES
Description
General part information
9007MS04G0500
Switch SPDT Chassis Mount
Technical Specifications
Parameters and characteristics for this part
| Specification | 9007MS04G0500 |
|---|---|
| Actuator Type | No Lever, Side Rotary |
| Circuit | SPDT |
| Current Rating | 100 mA, 30 mA |
| Electrical Life (Cycles) | 100000 Cycles |
| Ingress Protection Description | Waterproof, Dust Tight |
| Ingress Protection IP Rating | IP67 |
| Mechanical Life (Cycles) | 10000000 Cycles |
| Mounting Type | Chassis Mount |
| Operating Temperature (Max) | 104 °C |
| Operating Temperature (Min) | -40 °C |
| Switch Function | On-Mom |
| Termination Style | Cable Leads |
| Voltage Rating - AC | 125 V |
| Voltage Rating - DC | 28 V |
