HE100.02.16.01.00.00.000
ActiveHAUBER Elektronik
VIBRATION SENSOR EX IB
HE100.02.16.01.00.00.000
ActiveHAUBER Elektronik
VIBRATION SENSOR EX IB
Description
General part information
HE100.02.16.01.00.00.000
Vibration Sensor Analog Screw Mount Connector
Technical Specifications
Parameters and characteristics for this part
| Specification | HE100.02.16.01.00.00.000 |
|---|---|
| Features | Intrinsically Safe, Explosion Proof |
| Mounting Type | Screw Mount |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -40 °C |
| Output Type | Analog |
| Package / Case | Cylinder, Threaded - M8 |
| Power - Rated Current | 25 mA |
| Power - Rated Voltage (Max) | 30 V |
| Power - Rated Voltage (Min) | 10 V |
| Sensing Range (Max) | 1 kHz |
| Sensing Range (Min) | 1 Hz |
| Sensor Type | Vibration |
| Termination | Connector |
