Description
General part information
50LSQ10000M36X50
10000 µF 50 V Aluminum Electrolytic Capacitors Radial, Can - Screw Terminals 3000 Hrs @ 85°C
Technical Specifications
Parameters and characteristics for this part
| Specification | 50LSQ10000M36X50 |
|---|---|
| Applications | General Purpose |
| Capacitance | 10000 µF |
| Height - Seated (Max) | 2.087 in |
| Lifetime | 3000 Hrs |
| Mounting Type | Chassis Mount |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Can - Screw Terminals, Radial |
| Polarization | Polar |
| Ripple Current | 4.3 A, 4.644 A |
| Size / Dimension Diameter | 1.417 in |
| Tolerance | 20 % |
| Voltage - Rated | 50 V |
