Specification	9SX1500G

AC Outlets (Count)	8 count
Applications	General Purpose, Industrial Control
Approval Agency	cUL, UL
Backup Time - Max Load	3 minutes
Cord Length	8 ft
Form	Tower
Height	9.9 in
Input Connector	IEC 320-C14
Media Lines Protected	RS-232
Output Connector	IEC 320-C13
Output Connector Pin Count	8
Power - Rated (VA)	1.5 kVA
Power - Rated (W)	1350 W
Size / Dimension Length	17.1 in
Size / Dimension Width	6.3 in
Type	Online (Double Conversion)
Voltage - Input	208 VAC
Voltage - Output	208V, 220V, 200V, 230V, 250V, 240V
Voltage - Output (1)	200 V
Voltage - Output (2)	208 V
Voltage - Output (3)	220 V
Voltage - Output (4)	230 V
Voltage - Output (5)	240 V
Voltage - Output (6)	250 V
