Specification	XCKU115-3FLVB2104E

Mounting Type	Surface Mount
Number of I/O	702
Number of LABs/CLBs	82920
Number of Logic Elements/Cells	1451100
Operating Temperature (Max)	100 °C
Operating Temperature (Min)	0 °C
Package / Case	2104-BBGA, FCBGA
Package Length	47.5 mm
Package Name	2104-FCBGA
Package Width	47.5 mm
Total RAM Bits	77721600 bits
Voltage - Supply (Maximum)	1.03 V
Voltage - Supply (Minimum)	0.97 V

XCKU115 Series

Part	Total RAM Bits	Number of I/O	Package / Case	Number of LABs/CLBs	Voltage - Supply (Minimum)	Voltage - Supply (Maximum)	Operating Temperature (Max)	Operating Temperature (Min)	Mounting Type	Number of Logic Elements/Cells	Package Width	Package Name	Package Length
AMD / Xilinx XCKU115-2FLVD1517I	77721600 bits	338	1517-BBGA FCBGA	82920	0.922 V	0.979 V	100 °C	-40 °C	Surface Mount	1451100	40 mm	1517-FCBGA	40 mm
AMD / Xilinx XCKU115-2FLVA1517I	77721600 bits	624	1517-BBGA FCBGA	82920	0.922 V	0.979 V	100 °C	-40 °C	Surface Mount	1451100	40 mm	1517-FCBGA	40 mm
AMD / Xilinx XCKU115-1FLVB2104I	77721600 bits	702	2104-BBGA FCBGA	82920	0.922 V	0.979 V	100 °C	-40 °C	Surface Mount	1451100	47.5 mm	2104-FCBGA	47.5 mm
AMD / Xilinx XCKU115-2FLVB1760I	77721600 bits	702	1760-BBGA FCBGA	82920	0.922 V	0.979 V	100 °C	-40 °C	Surface Mount	1451100	42.5 mm	1760-FCBGA	42.5 mm
AMD / Xilinx XCKU115-2FLVB2104I	77721600 bits	702	2104-BBGA FCBGA	82920	0.922 V	0.979 V	100 °C	-40 °C	Surface Mount	1451100	47.5 mm	2104-FCBGA	47.5 mm
AMD / Xilinx XCKU115-2FLVD1924I	77721600 bits	832	1924-BBGA FCBGA	82920	0.922 V	0.979 V	100 °C	-40 °C	Surface Mount	1451100	45 mm	1924-FCBGA	45 mm
AMD / Xilinx XCKU115-1FLVD1924I	77721600 bits	832	1924-BBGA FCBGA	82920	0.922 V	0.979 V	100 °C	-40 °C	Surface Mount	1451100	45 mm	1924-FCBGA	45 mm
AMD / Xilinx XCKU115-2FLVF1924I	77721600 bits	728	1924-BBGA FCBGA	82920	0.922 V	0.979 V	100 °C	-40 °C	Surface Mount	1451100	45 mm	1924-FCBGA	45 mm
AMD / Xilinx XCKU115-1FLVF1924I	77721600 bits	728	1924-BBGA FCBGA	82920	0.922 V	0.979 V	100 °C	-40 °C	Surface Mount	1451100	45 mm	1924-FCBGA	45 mm
AMD / Xilinx XCKU115-1FLVA1517I	77721600 bits	624	1517-BBGA FCBGA	82920	0.922 V	0.979 V	100 °C	-40 °C	Surface Mount	1451100	40 mm	1517-FCBGA	40 mm
