1-282858-1
ActiveTE Connectivity AMP Connectors
FIXED TERMINAL BLOCKS RCPT 11P SIDE
1-282858-1
ActiveTE Connectivity AMP Connectors
FIXED TERMINAL BLOCKS RCPT 11P SIDE
Description
General part information
1-282858-1
11 Position PCB Terminal Block, Header, Wire-to-Board, 10 mm [.394 in] Centerline, 1 Row, 90° Wire Entry Angle, 30 – 12 AWG, .05 – 3 mm² Wire, 600 VAC
Technical Specifications
Parameters and characteristics for this part
| Specification | 1-282858-1 |
|---|---|
| Color | Green |
| Current | 24 A |
| Features | Interlocking (Side) |
| Mating Orientation | Horizontal with Board |
| Mounting Type | Through Hole |
| Number of Levels | 1 |
| Pitch | 0.394 in |
| Positions Per Level | 11 |
| Voltage | 600 V |
| Wire Gauge (AWG) (Max) | 30 AWG |
| Wire Gauge (AWG) (Min) | 12 AWG |
| Wire Termination | Rising Cage Clamp, Screw |
