2N2222AUA
ActiveTT Electronics/BI
TRANS NPN 50V 0.8A CERAMIC SMD
2N2222AUA
ActiveTT Electronics/BI
TRANS NPN 50V 0.8A CERAMIC SMD
Description
General part information
2N2222AUA
TRANS NPN 50V 0.8A CERAMIC SMD
Technical Specifications
Parameters and characteristics for this part
| Specification | 2N2222AUA |
|---|---|
| Current - Collector (Ic) (Max) | 800 mA |
| Current - Collector Cutoff (Max) | 50 nA |
| DC Current Gain (hFE) (Min) | 75 |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 200 °C |
| Operating Temperature (Min) | -65 °C |
| Package / Case | 4-CLCC |
| Package Name | Ceramic SMD |
| Power - Max | 0.5 W |
| Transistor Type | NPN |
| Vce Saturation (Max) | 1 V |
| Voltage - Collector Emitter Breakdown (Max) | 50 V |
