B72210M0301K000
ObsoleteEPCOS - TDK Electronics
10MM, 300VAC, 10% SMD VARISTOR V
B72210M0301K000
ObsoleteEPCOS - TDK Electronics
10MM, 300VAC, 10% SMD VARISTOR V
Description
General part information
B72210M0301K000
470 V 6 kA Varistor 1 Circuit Surface Mount, MLCV 2-SMD, J-Lead
Technical Specifications
Parameters and characteristics for this part
| Specification | B72210M0301K000 |
|---|---|
| Capacitance | 475 pF |
| Current - Surge | 6000 A |
| Energy | 140 J |
| Maximum AC Volts | 300 V |
| Maximum DC Voltage | 385 V |
| Mounting Type | MLCV, Surface Mount |
| Number of Circuits | 1 |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | 2-SMD, J-Lead |
| Varistor Voltage (Max) | 517 V |
| Varistor Voltage (Min) | 423 V |
| Varistor Voltage (Typ) | 470 V |
