PEWM3920FL200R9
ActiveC&B Eureka Innovations
0.0002 OHM 1% 12W 150PPM/C
PEWM3920FL200R9
ActiveC&B Eureka Innovations
0.0002 OHM 1% 12W 150PPM/C
Description
General part information
PEWM3920FL200R9
200 µOhms ±1% 12W Chip Resistor 3920 (1052 Metric) Automotive AEC-Q200, Current Sense Metal Element
Technical Specifications
Parameters and characteristics for this part
| Specification | PEWM3920FL200R9 |
|---|---|
| Composition | Metal Element |
| Features | Current Sense, Automotive AEC-Q200 |
| Height - Seated (Max) | 0.091 in |
| Number of Terminations | 2 |
| Operating Temperature (Max) | 170 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | 3920 (1052 Metric) |
| Package Name | 3920 |
| Power (Watts) | 12 W |
| Ratings | AEC-Q200 |
| Resistance | 200 µOhms |
| Size / Dimension Length | 0.394 in |
| Size / Dimension Width | 0.205 in |
| Temperature Coefficient | 150 ppm/¯C |
| Tolerance | 1 % |
