T48C862M-R4-TNQ
ObsoleteMicrochip Technology
RF XMITTER FM/FSK 433MHZ 24SOIC
T48C862M-R4-TNQ
ObsoleteMicrochip Technology
RF XMITTER FM/FSK 433MHZ 24SOIC
Description
General part information
T48C862M-R4-TNQ
RF Transmitter FM, FSK 433MHz 10dBm 32kBaud PCB, Surface Mount Antenna 24-LSSOP (0.173", 4.40mm Width)
Technical Specifications
Parameters and characteristics for this part
| Specification | T48C862M-R4-TNQ |
|---|---|
| Antenna Connector | PCB, Surface Mount |
| Current - Transmitting | 9.5 mA |
| Data Interface | PCB, Surface Mount |
| Data Rate (Max) | 32 kBaud |
| Frequency | 433 MHz |
| Memory Size | 1 KB |
| Memory Size (EEPROM) | 1 KB |
| Memory Size (RAM) | 1 KB |
| Memory Type | EEPROM, RAM |
| Modulation or Protocol | FM, FSK |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -40 °C |
| Package Length | 0.173 in |
| Package Name | 24-LSSOP, 24-SSO |
| Package Width | 4.4 mm |
| Power - Output | 10 dBm |
| Voltage - Supply (Maximum) | 4 V |
| Voltage - Supply (Minimum) | 2 V |
