Specification	MKP1848C62050JP4

Applications	DC Filtering, DC Link
Capacitance	20 µF
Dielectric Material	Metallized, Polypropylene (PP)
ESR (Equivalent Series Resistance)	8 mOhm
Features	Low ESL, Long Life, Low ESR
Height - Seated (Max)	1.398 in
Lead Spacing	1.476 in
Mounting Type	Through Hole
Operating Temperature	105 °C
Package Leads	4 Leads
Package Name	Radial
Size / Dimension Length	1.693 in
Size / Dimension Width	0.728 in
Termination	PC Pins
Tolerance	5 %
Voltage Rating - DC	500 V
