CY8C4247FLI-BL493T

Active

Infineon Technologies

IC MCU 32BIT 128KB FLASH 68WLCSP

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

CY8C4247FLI-BL493T

Active

Infineon Technologies

IC MCU 32BIT 128KB FLASH 68WLCSP

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	CY8C4247FLI-BL493T

Connectivity	IrDA, SmartCard, I2C, SPI, SSP, LINbus, Microwire, UART/USART
Core Processor	ARM® Cortex®-M0
Core Size	32-Bit Single-Core
Data Converters [custom]	12 b
Data Converters [custom]	8
Mounting Type	Surface Mount
Number of I/O	36
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Oscillator Type	Internal
Package / Case	WLCSP, 68-XFBGA
Peripherals	POR, SmartSense, PWM, LVD, Bluetooth, LCD, WDT, Cap Sense, Brown-out Detect/Reset, SmartCard
Program Memory Size	128 KB
Program Memory Type	FLASH
RAM Size	16 K
Speed	48 MHz
Supplier Device Package	68-WLCSP
Supplier Device Package [x]	3.52
Supplier Device Package [y]	3.91
Voltage - Supply (Vcc/Vdd) [Max]	5.5 V
Voltage - Supply (Vcc/Vdd) [Min]	1.71 V

CY8C4247 Series

Part	Core Processor	Program Memory Size	Voltage - Supply (Vcc/Vdd) [Min]	Voltage - Supply (Vcc/Vdd) [Max]	Package / Case	Speed	Supplier Device Package	Data Converters	Oscillator Type	Core Size	Operating Temperature [Max]	Operating Temperature [Min]	Mounting Type	Program Memory Type	Connectivity	RAM Size	Peripherals	Number of I/O	Data Converters	Data Converters [custom]	Data Converters [custom]	Supplier Device Package [x]	Supplier Device Package [y]
Infineon Technologies CY8C4247LTQ-M475	ARM® Cortex®-M0	128 KB	1.71 V	5.5 V	68-VFQFN Exposed Pad	48 MHz	68-QFN (8x8)	A/D 1x12b SAR D/A 4x8b	Internal	32-Bit Single-Core	105 °C	-40 °C	Surface Mount	FLASH	I2C IrDA LINbus Microwire SmartCard SPI SSP UART/USART	16 K	Brown-out Detect/Reset Cap Sense LCD LVD POR PWM SmartSense WDT	55
Infineon Technologies CY8C4247AZQ-M485T	ARM® Cortex®-M0	128 KB	1.71 V	5.5 V	64-LQFP	48 MHz	64-TQFP (10x10)		Internal	32-Bit Single-Core	105 °C	-40 °C	Surface Mount	FLASH	CANbus I2C IrDA LINbus Microwire SmartCard SPI SSP UART/USART	16 K	Brown-out Detect/Reset CapSense DMA LCD LVD POR PWM SmartSense WDT	51	2 channels 2 channels 7 b 8 b 12 b 16 channels
Infineon Technologies CY8C4247LTI-L475	ARM® Cortex®-M0	128 KB	1.71 V	5.5 V	68-VFQFN Exposed Pad	48 MHz	68-QFN (8x8)	A/D 16x12b SAR D/A 4x8b	Internal	32-Bit Single-Core	85 °C	-40 °C	Surface Mount	FLASH	I2C IrDA LINbus Microwire SmartCard SPI SSP UART/USART USB	16 K	Brown-out Detect/Reset Cap Sense DMA LVD POR PWM SmartSense WDT	57
Infineon Technologies CY8C4247AZI-L445	ARM® Cortex®-M0	128 KB	1.71 V	5.5 V	64-LQFP	48 MHz	64-TQFP (10x10)	A/D 16x12b D/A 2x7b D/A 2x8b	Internal	32-Bit Single-Core	85 °C	-40 °C	Surface Mount	FLASH	I2C IrDA LINbus Microwire SmartCard SPI SSP UART/USART USB	16 K	Brown-out Detect/Reset CapSense DMA LVD POR PWM SmartSense WDT	53
Infineon Technologies CY8C4247BZI-L479T	ARM® Cortex®-M0	128 KB	1.71 V	5.5 V	124-VFBGA	48 MHz	124-VFBGA (9x9)	A/D 16x12b SAR D/A 4x8b	Internal	32-Bit Single-Core	85 °C	-40 °C	Surface Mount	FLASH	I2C IrDA LINbus Microwire SmartCard SPI SSP UART/USART USB	16 K	Brown-out Detect/Reset Cap Sense DMA LVD POR PWM SmartSense WDT	98
Infineon Technologies CY8C4247AXQ-M485	ARM® Cortex®-M0	128 KB	1.71 V	5.5 V	64-LQFP	48 MHz	64-TQFP		Internal	32-Bit Single-Core	105 °C	-40 °C	Surface Mount	FLASH	CANbus I2C IrDA LINbus Microwire SmartCard SPI SSP UART/USART	16 K	Brown-out Detect/Reset CapSense DMA LCD LVD POR PWM SmartSense WDT	51	2 channels 2 channels 7 b 8 b 12 b 16 channels
Infineon Technologies CY8C4247LQI-BL493	ARM® Cortex®-M0	128 KB	1.71 V	5.5 V	56-UFQFN Exposed Pad	48 MHz	56-QFN		Internal	32-Bit Single-Core	85 °C	-40 °C	Surface Mount	FLASH	I2C IrDA LINbus Microwire SmartCard SPI SSP UART/USART	16 K	Bluetooth Brown-out Detect/Reset Cap Sense LCD LVD POR PWM SmartCard SmartSense WDT	36		12 b	8	7	7
Infineon Technologies CY8C4247FLI-BL493T	ARM® Cortex®-M0	128 KB	1.71 V	5.5 V	68-XFBGA WLCSP	48 MHz	68-WLCSP		Internal	32-Bit Single-Core	85 °C	-40 °C	Surface Mount	FLASH	I2C IrDA LINbus Microwire SmartCard SPI SSP UART/USART	16 K	Bluetooth Brown-out Detect/Reset Cap Sense LCD LVD POR PWM SmartCard SmartSense WDT	36		12 b	8	3.52	3.91
Infineon Technologies CY8C4247LTI-L445	ARM® Cortex®-M0	128 KB	1.71 V	5.5 V	68-VFQFN Exposed Pad	48 MHz	68-QFN (8x8)	A/D 16x12b D/A 2x7b D/A 2x8b	Internal	32-Bit Single-Core	85 °C	-40 °C	Surface Mount	FLASH	I2C IrDA LINbus Microwire SmartCard SPI SSP UART/USART USB	16 K	Brown-out Detect/Reset CapSense DMA LVD POR PWM SmartSense WDT	57
Infineon Technologies CY8C4247AZI-L423T	ARM® Cortex®-M0	128 KB	1.71 V	5.5 V	48-LQFP	48 MHz	48-TQFP (7x7)	A/D 16x12b D/A 2x7b D/A 2x8b	Internal	32-Bit Single-Core	85 °C	-40 °C	Surface Mount	FLASH	I2C IrDA LINbus Microwire SmartCard SPI SSP UART/USART	16 K	Brown-out Detect/Reset CapSense DMA LCD LVD POR PWM SmartSense WDT

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tape & Reel (TR)	2000	$ 6.21

Description

General part information

CY8C4247 Series

ARM® Cortex®-M0 PSOC® 4 CY8C4xx8 BLE Microcontroller IC 32-Bit Single-Core 48MHz 128KB (128K x 8) FLASH 68-WLCSP (3.52x3.91)

Documents

Technical documentation and resources
