DS2484EVKIT#
ActiveAnalog Devices Inc./Maxim Integrated
EVALUATION KIT FOR DS2484 (SINGL
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | DS2484EVKIT# | DS2484 Series |
|---|---|---|
| Current - Supply | - | 300 µA |
| Embedded | Yes, MCU | Yes, MCU |
| Function | 1-Wire to I2C | 1-Wire to I2C, Controller |
| Interface | - | I2C |
| Operating Temperature | - | 85 °C |
| Operating Temperature | - | -40 °C |
| Package / Case | - | 8-WFDFN Exposed Pad, SOT-23-6 |
| Primary Attributes | 1.8 V, 3.3 V | 1.8 - 3.3 V |
| Protocol | - | 1-Wire® |
| Secondary Attributes | On-Board Test Points | On-Board Test Points |
| Supplied Contents | Board(s) | Board(s) |
| Supplier Device Package | - | 8-TDFN (2x3), SOT-6 |
| Type | Interface | Interface |
| Utilized IC / Part | DS2484 | DS2484 |
| Voltage - Supply | - | 1.71 V |
| Voltage - Supply | - | 5.25 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 113.34 | |
DS2484 Series
EVALUATION KIT FOR DS2484 (SINGL
| Part | Primary Attributes | Utilized IC / Part | Type | Embedded | Secondary Attributes | Function | Supplied Contents | Package / Case | Voltage - Supply [Min] | Voltage - Supply [Max] | Supplier Device Package | Interface | Protocol | Current - Supply | Operating Temperature [Max] | Operating Temperature [Min] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Analog Devices Inc./Maxim Integrated DS2484EVKIT# | 1.8 V, 3.3 V | DS2484 | Interface | Yes, MCU | On-Board Test Points | 1-Wire to I2C | Board(s) | |||||||||
Analog Devices Inc./Maxim Integrated DS2484Q+T | Controller | 8-WFDFN Exposed Pad | 1.71 V | 5.25 V | 8-TDFN (2x3) | I2C | 1-Wire® | 300 µA | 85 °C | -40 °C | ||||||
Analog Devices Inc./Maxim Integrated DS2484R+U | Controller | SOT-23-6 | 1.71 V | 5.25 V | SOT-6 | I2C | 1-Wire® | 300 µA | 85 °C | -40 °C | ||||||
Analog Devices Inc./Maxim Integrated DS2484Q+U | Controller | 8-WFDFN Exposed Pad | 1.71 V | 5.25 V | 8-TDFN (2x3) | I2C | 1-Wire® | 300 µA | 85 °C | -40 °C |
Description
General part information
DS2484 Series
DS2484 1-Wire to I2C Interface Evaluation Board
Documents
Technical documentation and resources
